Ⅰ. TY-Q Turbine Oil Recycling Machine Usage
The Turbine Oil Recycling Machine is equipped with precision filtration, vacuum drying, coalescence separation and three-dimensional spiral atomization technology. After processing, the gas, moisture, acid and foam in the emulsified oil will become clear and meet the use standards. Widely used in power, chemical, paper, petroleum and other industries. Can effectively ensure the safe operation of the turbine lubrication system.
Ⅱ. TY-Q Turbine Oil Recycling Machine Working Principle
Turbine Oil Recycling Machine adopts the principle of vacuum separation and precision mechanical purifier. It adopts a variety of technologies such as molecular adsorption, vacuum drying, mechanical filtration, etc. The lubricant vacuum purifier is a complete machine without any attached mechanical equipment.
Ⅲ. TY-Q Turbine Oil Recycling Machine Function.
3.1 improve the cleanliness of lubricating system on Dilute Oil Station and oil tank, impurity and dewatering degassing and impurities removal.
3.2 It can remove not only 100% free water and 99.9% dissolve water, but also 100% free gas and 98% dissolve gas, and the ends oil will meeting the national using standard.
Patent Automatic Vibration defoaming technology
| most suppliers use this kind of technology for defoaming, actually the truth is they defoaming by make the air into the vacuum evaporation tank, the air with moisture and impurities, which will make the oil be polluted secondary. |
| This is our patent technology in almost 10 years experience in transformer oil filtration. The design like bellow. |
Ⅳ. Treated Turbine Oil Parameters
Items | unit | Treatment parameter | est Method |
Mechanical impurities | ％ | 无 | GB/T511 |
Demulsibility number | Min | ≤15 | GB/T7605 |
Moisture | Mg/L | ≤50PPM | GB/T7600 |
Acid value | mgkoH/g | ≤0.3 | GB/T264 |
Cleanness-degree | Grade | ≤6 | NAS1638 |
Filter precision | ≤3um | ||
